Name |
Details |
|
Model |
GYB-2-57/500 |
|
Rate Pressure |
500 bar / 7250 psi |
|
Water flow |
57 L/min |
|
Plunger diameter |
26mm |
|
Inpurt speed |
1480 rpm |
|
Pump speed |
405 rpm |
|
Plunger stroke |
95 mm |
|
Electric motor |
55kw，380V 50HZ，voltage can customized |
1. For the machine, pump is use the tech. of Germany WOMA.
2. Two guns work at same time
3. Pressure is stable and reliable, easy to be adjust.
4. It is installed with a high-pressure alarm and high-temperature alarm for water conservation.
5. The high pressure gun is use the stainless steel material, Max pressure 500bar
6. Has two filter, for inlet water filter out. Could be filter out the tiny particles from the inlet water. Good for long-working life of the pump.
7. Has explosion-proof system, could explosion-proof if you use this machine on chemical plant.
8. With a high-pressure alarm and high-temperature alarm for water conservation.
9. Could be used on starch factory, steel mill, chemical plant, power plant, for cleaning and maintenance.
|
Name |
Quantity |
|
High pressure hose |
50 meters |
|
High pressure gun |
2 sets |
|
Fan-shaped nozzle |
2 pcs |
|
Cylinder-shaped nozzle |
2 pcs |
|
Rotating nozzle |
2pcs |
|
Spare Parts |
2 sets |
1. Many area industrial cleaning purpose, heat exchanger tube cleaning, condenser tube cleaning, pipe cleaning, reactor tank cleaning, filter screen cleaning, boil cleaning, tank cleaning, etc…
2. Pipe pressure test, valve / hose pressure test, hydro pressure test, etc
3. Water injection
4. Cement plant pipe cleaning, grease remove from the equipment surface, fouling layer removal
5. Construction industry, car/truck cleaning, mixing drum/tank cleaning, tar/cement/agglutinant cleaning, etc
6. Food processing plant, mixing tank cleaning, grease/ fouling layer / residual removal, evaporator/boil cleaning, etc
7. Shipyard rust removal, paint removal, ship hull cleaning, boat surface cleaning, dirt removal, sea creatures remove from the hull bottom.
8. Metallurgy plant, heat exchanger tube cleaning, boil, feed tank, warehouse dirt cleaning, descale removal
9. Machine producing plant, volume / pipe / tank / rust / oxide skin cleaning…
Please contact us for free quotation by form below. We promise the quickest response within 24 hours:
