Hydro Jetting Equipment Price

Product Details

Name

Details

Model

GYB-5-70/1200

Rate Pressure

1200bar(180kpsi)

Water flow

70L/min

Plunger diameter

26mm

Inpurt speed

1480 rpm

Pump speed

366 rpm

Plunger stroke

120 mm

Electric motor

160kw

Dimension

3200mm length*1600mm width*1700mm height

Main Features

1.High pressure pump introduced Germany KAMAT advanced technology;

2.Stainless steel pump head; Stainless steel nickel-plated plunger, forced water cooling;

3.The water seal is made of ductile iron imported from the United States;

4.Good heat dissipation, hard texture, not easy to deformation;

5.The crankcase at the power end is lubricated with forced lubrication, which reduces the temperature of the crankcase;

6.Smooth and reliable transmission, reduce friction coefficient, improve lubricity;

7.Pure high pressure water physical cleaning, no need to add any chemical agents when used, no pollution, is the national promotion of green environmental protection high-tech products.

CONFIGURATION LIST

high pressure hose

30M

cleaning nozzle

1set

High pressure gun

1pc

Flexible lance

1pc

Foot control valve

1set

APPLICATION FIELD

1.Industrial Pipe Cleaning

2.Heat Exchanger pipe Cleaning

3.Boiler Tube Cleaning

4.Petrochemical Plant Cleaning

5.Condenser cleaning

6.Evaporator cleaning

7.Pipe Descaling

High Pressure Water Jetting equipment adopts ultra high pressure stream to get the pressure to clean the surface of the material like painting and rust and cleaning the insider of the tube pipe and tank and heat exchanger.

Operating pressures from 3 00 bar to 3000 bar it is ideally suited for a wide variety of cleaning work, e.g. in the chemical industry, oil and gas industries as well as in the area of ship cleaning.

The hydro jetting machine is a machine that uses a power device to make a high-pressure plunger pump generate high-pressure water to wash the surface of an object. It can peel off and wash away dirt to achieve the purpose of cleaning the surface of an object. Because it uses a high-pressure water column to clean dirt, high-pressure cleaning is also recognized by the world as one of the most scientific, economical and environmentally friendly cleaning methods.

Working principle

The impact force of water is greater than the adhesion between the dirt and the surface of the object, and the high-pressure water will peel off and wash away the dirt to achieve a cleaning device that cleans the surface of the object. Because it uses a high-pressure water column to clean the dirt, only a little detergent needs to be added for very stubborn oil stains, otherwise the foam generated by the strong water pressure is enough to take away general dirt.

Water jet blasting system uses pressure water from 1000bar to 2800bar used to clean the drain. And sewer and tube insider cleaning with 3D cleaning head.

It also can be used for paint for oil tank cleaning. And protective coating removal for ship hull, road marking or zebra crossing removal. This method is perfect for internal and external surfaces. Because the spray gun operator is able to access those "hard to reach" areas.
